CEFLA NewTom GO - Page 64

64
OPERATOR'S MANUAL
EN
Version with floor column and 45° wall mount
Weight (basic machine)
For 2D machine only: 102 kg
For 3D machine only: 108 kg
Maximum overall dimensions in diagram (basic
machine)
1030 x 1213 mm
Height
Min 1636 mm Max 2256 mm
Use the installation template for wall mounting.
