Calibrating the system
______________________________________________________________________________________
NewTom VGi evo – Service Manual rev 6 8-11
Calibration backup
At the end of the calibration a backup must be done in order to store a copy of the modified files. Follow next steps to
perform the backup process.
1. From the main menu select File → Settings Backup.
2. The “Import/Export path setup” window will appear. Select the “Change Path” button to select the directory
where you wish to backup the files. Use the “Add folder” button to create a new folder inside the selected path.
3. Once the destination path is ready, select the “Go on” button to start the backup process.
4. At the end a message will appear informing that the Backup procedure has successfully completed.
5. Burn a CD with the contents of the directory in which you have just backed up the files.
NOTE:
The CD containing the calibration files should be labelled with
the serial number of the machine and the date of the calibration
and shall be kept in a safe place. Remember that these data are
essential in case of a computer failure or crash.
View calibration
Even from the normal user mode, it is possible to view the machine calibrations selecting the View menu at the opening
of the NNT software and choosing the desired calibration.
It is also possible to print the calibration (selecting File
Print) or to save it in PDF format (selecting File
Save as
PDF).
Factory backup folder
Starting from 18th December 2017 all the data listed below will be found in the "C:\NNT\FACTORY_BACKUP" folder on all
Workstations and into the NNT Installation DVD with the device serial number:
One extra copy of the factory calibration data
Installer of the current version of the iRysNNT software at the moment the unit was manufactured
User manuals
Technical manuals (in a zipped file with password "Cefla", for field engineer use only)
