USER’S MANUAL
Supports ACPI Power states C0, C1, S0, and S5 •
•
•
•
•
•
•
•
•
•
Supports Zircom UL BMC and IPMI 1.5 specification
Integrates option ROM and PXE ROM to support on-board Gigabit NIC
Integrates option ROM to support on-board dual-channel SCSI controller
BIOS Firmware
A base firmware supports the following BMC features:
Remote power on/off
Remote server reset
Remote LED indicator control
Remote flash update
IPMI 1.5 over LAN
The BIOS supports the following features with software:
o Voltage reading from VRM for CPU and DIMM slots
o CPU thermal diode reporting
o Chassis temperature reporting
o FAN status reporting
7-2
