4.3.4 Calibraon and Auto Bed Leveling (ABL)
Calibrate the printheads and surface probe. The surface probe is used for ABL.
ABL probes the bed at three points to enable bed-leveling compensaon. It uses a matrix to
compensate for lt in the bed or print surface.
The surface probe only needs to be calibrated once. The printer will remember this calibraon and
apply it for each print. You must enable ABL before prinng.
1. Printhead 1 - Calibraon tab for printhead 1.
2. Printhead 2 - Calibraon tab for printhead 2.
3. Printhead 3 - Calibraon tab for printhead 3.
4. Surface probe - Calibraon tab for the surface probe.
5. Enable ABL - Turn ABL on or o. ABL is enabled aer calibrang the surface probe and going
back to the Printhead 1 tab.
The ABL should be enabled aer calibrang the surface probe and going back to the
Printhead 1 tab.
6. Z axis command - Controls the posion of the print bed along the Z axis.
7. X, Y axis command - Controls the posion of the printhead and the surface probe along the X
and Y axis.
8. Apply command - Register the calibraon sengs.
6
7
54
8
1 2 3
