Page 20SKU 96549
For technical questions, please call 1-800-444-3353.
Camshaft and Rocker Valve Assembly Diagram
Note: When ordering parts from this list, specify: Parts List E, CAMSHAFT AND ROCKER
VALVE ASSEMBLY and the ITEM No.
Camshaft and Rocker Valve Parts List
Part Description Qty
1E Lock Nut 2
2E Sleeve 2
3E Valve, Rocker 2
4E Bolt, Adjusting, Valve Gap 2
5E Valve, Rocker, Assembly 2
6E Pusher Guide 1
7E Pusher 2
8E Tappet 2
Part Description Qty
9E Spring, Extension 1
10E Camshaft Assembly 1
11E Valve, Exhaust 1
12E Valve, Intake 1
13E Spring, Valve 2
14E Spring Seat, Intake Valve 1
15E Spring Seat, Exhaust Valve 1
16E Cap 1
