Page 26SKU 96549
For technical questions, please call 1-800-444-3353.
Regulator Control Assembly Diagram
Note: When ordering parts from this list, specify: Parts List L, REGULATOR CONTROL
ASSEMBLY and the ITEM No.
Regulator Control Parts List
Part Description Qty
1L Nut, M6 1
2L Panel, Setting 1
3L Spring Patch 1
4L Hand Grip 1
5L Washer 1
6L Bolt, M5x25 1
7L Spring, Regulating 1
8L Support Panel Assembly 1
Part Description Qty
9L Spring 1
10L Spring, Back 1
11L Spring, Fine Regulating 1
12L Rod, Pull 1
13L Bolt, Lock 1
14L Arm, Regulating 1
15L Nut, M6 1
16L Regulating Frame Assembly 1
To Next Page
