Page 28SKU 96549
For technical questions, please call 1-800-444-3353.
Ignition Coil Assembly Diagram
Note: When ordering parts from this list, specify: Parts List N, IGNITION COIL ASSEMBLY
and the ITEM No.
Ignition Coil Parts List
Part Description Qty
1N Screw, M6x22 2
2N Engine Stop Cable 1
3N Ignition Coil 1
4N Spark Plug Cap 1
5N Ignition Coil Assembly 1
