Page 27SKU 96549
For technical questions, please call 1-800-444-3353.
Flywheel Assembly Diagram
Note: When ordering parts from this list, specify: Parts List M, FLYWHEEL ASSEMBLY and
the ITEM No.
Flywheel Parts List
Part Description Qty
1M Nut, M14x1.5 1
2M Starting Flange 1
3M Flywheel Fan 1
4M Flywheel 1
