Central Pneumatic 34202 - Wheel and Foot Attachment; Safety Valve Installation

Wheels and Foot
See Figure 8.
5
3
2
4
3
3
2
Figure 8 - Wheel and Foot Attachment
Step 1: Get out the two WHEELS (#2), the three COTTER PINS (#3), the FOOT (#4) and the
AXLE (#5).
Step 2: Attach the FOOT to the TANK (#1) using one of the COTTER PINS.
Step 3: Attach one of the WHEELS to the AXLE using one of the COTTER PINS.
Step 4: Slide the AXLE through the hole in the bottom of the two HANDLE BARS (#6).
Step 5: Attach the other WHEEL to the AXLE using the remaining COTTER PINS.
Safety Valve
Step 1: Screw the SAFETY VALVE (#10) into the hole in the top of the TANK (#1).
Page #11 -- SKU 34202
