Centurion D3 - Set-Up Troubleshooting Guide

Page 33
Set-up Troubleshooting GuideSet-up Troubleshooting Guide
SET-UP
STEP
PROBLEM POSSIBLE CAUSES & SOLUTIONS TO PROBLEM
4or18
SET light is not on:
L2 is not on:
STATUS light did not
flash 5 times:
L1 is flashing:
Check that the SET link is correctly fitted. Fit and remove the
link a few times to ensure good contact, restart from step 2.
All sources of power on the card must be removed. Check by
confirming that all the lights turn off, before reconnecting the
power with the set link fitted, restart from step 2.
The controller did not “boot-up” correctly. Try to fit the charger
plug before reconnecting the battery, restart from step 2.
Check for and remove latching inputs on the TRG terminal
then restart from step 2 on page 24.
10
There is a short click but
the
The STATUS light flashes
L2 turns on.
motor does not turn.
!
!
!
!
Check for loose connections or corrosion on battery
terminals.
If an external battery is used, check that the battery cables
are not too thin. They must be no less than 4
Check for low battery condition by following procedure A
on page 37.
Correct the problem, remove and refit the SET link and
start from step 8 on page 24.
The manual release mechanism is still in manual mode, restart
from step 6.
mm
2
!
!
!
The motor not being connected to the controller, or
The motor fuse could be blown, or
The motor is faulty. Check motor by connecting motor
leads directly to the battery.
There is a click, the
motor turns but the gate
does not move.
Three consecutive slow
relay clicks but motor
does not move.
10.2
Motor makes three short
opposing movements on
gate, L2 comes on.
Gate is fully open and
does not return to
complete the Automatic
Setup Routine. L2 and L1
are off.
!
The DOSS sensor system is faulty.
Is the DOSS harness
plugged in? If so, there could be a fault on the sensor,
cable or controller.
Is there any water or oil present in the DOSS sensor
area? Correct the problem as restart from step 5
!
!
!
Battery capacity too low to complete setup.
10.3
Gate runs full speed into
endstop.
!
Gate origin marker not present. See page 22 for fitting
instructions.
