page 29
Symptom
Cause
Action
Gate does not
operate and there
is no reaction from
any of the relays
on the VECTOR2
controller either.
(If the remote
transmitter is
pressed, only the
radio receiver
relay ‘clicks’).
There is an incorrect
trigger input to the
controller causing it
to malfunction
Gate lock not releas-
ing
Trouble-
shooting
guide
Check that the GREEN
(’Safe CLS’ and ‘Safe
OPN’) LED's on the
VECTOR2 controller are
ON.
Check that the GREEN
‘LCK/STP’ (holiday
lockout/emergency stop)
LED is ON
Check that the other RED
input LEDs (e.g. ‘TRG’,
‘PED’, ‘FRX’, etc) are OFF.
They must only light up
when the corresponding
input is activated
Try operating the system
using the RUN ( )
pushbutton on the control
card
Consult your installer if
there is a problem
Solenoid Lock: Check that
the lock is trying to
release. It will make a
distinctive ‘click’ sound
when energised. Then
check that the lock is not
being mechanically held
due to misalignment, dirt,
etc.
Magnetic Lock: Pull on the
lock when activating the
gate to release and feel
whether the lock is
releasing. Try disconnect-
ing the lock (remove wire
from terminal marked
‘Sol’)
Consult your installer if
there is a problem
