32 – Monitoring – User manual – v1.2
T1S and T2S Characteristics
556 Saturation alarm threshold 0 80 100 %
558 AC in is present (1:true 0:false) 0 1 1
570 Log near. Full thresh. (100-200) 100 180 200
Alarm Type (ID : 601 - 900) : Minor (1) - Major (2)- No Alarm (0)
681 80 . Brownout Derating 0 1 2
828 227 . DIG INP1 FAILURE 0 2 2
829 228 . DIG INP2 FAILURE 0 2 2
830 229 . REDUNDANCY LOST 0 1 2
831 230 . REDUND + 1LOST 0 2 2
832 231 . SYS SATURED (see parameter ID 556) 0 1 2
833 232 . MAIN SOURCE LOST 0 2 2
834 233 . SEC SOURCE LOST 0 1 2
835 234 . T2S BUS FAIL 0 2 2
836 235 . T2S FAILURE 0 2 2
843 242 . LOG NEARLY FULL (see parameter ID 560) 0 0 2
845 244 . CHECK LOG FILE 0 1 2
846 245 . SHUTDWON DC 1 0 1 2
847 246 . SHUTDWON DC2-->DC8 0 1 2
User Input Alarm Labels (ID : 901 - 950)
901 Digital input 1 label (max 16 characters) text DIG INP1 FAILURE** text
902 Digital input 2 label (max 16 characters) text DIG INP2 FAILURE** text
904 Input polarity (0:ShortCircuited-1; open) 0 0 1
ModBus Settings (ID : 951 - 1000)
951 T2S Modbus slave address (1 - 247) 1 1 247
952 Modbus baud rate (19200 or 9600) 19200
953 Modbus parity (0:no 1:odd 2:ev) 0 2 2
954 Modbus stop bits (1 or 2)
1 1 2
955 Modbus write password (max 16 characters) text Modbus_T2S text
ID 551: The default Value (255) means that this function is not used. When an other value is recorded (i.e. 230 ; this relay will
change when “redundancy will lost” and specific text will appears.
** ID 901 & 902: The customer is able to use these fields for specific custom message. Texts can be recorded with max 16
characters. The ID 901 is mainly use to give status of MBP and reduce the current in MBP transfer position.
