CE+T Power T1S - DC Groups Parameters Settings

49 – Monitoring – User manual – v1.2
T2S Configuration Parameters
;190; ;OUT 4 : phase shift ; ;0; ;deg;
;191; ;OUT 4 : Nominal Output Voltage ; ;230.0; ;V;
;200; ;OUT 5 : phase shift ; ;0; ;deg;
;201; ;OUT 5 : Nominal Output Voltage ; ;230.0; ;V;
;210; ;OUT 6 : phase shift ; ;0; ;deg;
;211; ;OUT 6 : Nominal Output Voltage ; ;230.0; ;V;
;220; ;OUT 7 : phase shift ; ;0; ;deg;
;221; ;OUT 7 : Nominal Output Voltage ; ;230.0; ;V;
;230; ;OUT 8 : phase shift ; ;0; ;deg;
;231; ;OUT 8 : Nominal Output Voltage ; ;230.0; ;V;
¾ The same for the phases 4 to 8
7.3 DC groups parameters settings
;260; ;DC 1 : Vdc_in Low Start ; ;44.0; ;V;
¾ Low DC Voltage where a higher value leads the DC/AC converter to re-start
;261; ;DC 1 : Vdc_in Low Transfer ; ;39.0; ;V;
¾ Low DC Voltage where a lower value leads to transfer the load from DCin to ACin
;262; ;DC 1 : Vdc_in Low Stop ; ;39.0; ;V;
¾ Low DC voltage where a lower value stops the DC/AC converter
;263; ;DC 1 : Vdc_in High Start ; ;58.0; ;V;
¾ High DC voltage where a higher value re-starts the DC/AC converter
;264; ;DC 1 : Vdc_in High Transfer ; ;61.0; ;V;
¾ High DC Voltage where a higher value leads to transfer the load from DCin to ACin
