48 – Monitoring – User manual – v1.2
T2S Configuration Parameters
;103; ;External clock (0 : OFF, 1 : ON); ;0; ;;
¾ Records the “External Clock” mode configuration Available from 177sw version
¾ Only used in 3 phase systems considered as single phase using a clock.
¾ Prevents any phase drift outside 120° between phases to protect delta 3 phase loads.
¾ 0 no protection in: phase drift is allowed.
¾ 1 protection in: no phase drift allowed, stops the system after 1 minute.
;104; ;Start without T2S (0 : No , 1 : Yes); ;0; ;;
¾ When this mode is activated, the TSI inverter is able to start without T2S. This solution doesn’t provide monitoring. In
this application we will use different backplane which include alarm relay. From 192 sw version
¾ 0do not allow the starting without T2S
¾ 1 allow starting TSI without T2S
;160; ;OUT 1 : phase shift ; ;0; ;deg;
;161; ;OUT 1 : Nominal Output Voltage ; ;230.0; ;V;
¾ Records the phase shift and the nominal Outlet voltage
;170; ;OUT 2 : phase shift ; ;240; ;deg;
;171; ;OUT 2 : Nominal Output Voltage ; ;230.0; ;V;
¾ Records the phase shift and the nominal Outlet voltage
;180; ;OUT 3 : phase shift ; ;120; ;deg;
;181; ;OUT 3 : Nominal Output Voltage ; ;230.0; ;V;
¾ Records the phase shift and the nominal Outlet voltage
