T2S Configuration Parameters
;94; ;Pdc Max (0 : function disabled); ;0; ;W;
¾ This feature allow to limit or reduce the INRUSH DC current when the system work on battery. To limit the current this
configuration line should limit the inrush DC current. To allow for the high capability this inverter is build with extra
capacitor running on 400VDC to provide the requested energy.
(Feature only available in Bravo HC system - T32H73E02S).
¾ 0 means no DC limitation
¾ 2000: power limitation at 2000W. (should be activate when battery capacity is lower than 300AH per 2500VA module
installed)
;100; ;Synchronization Tracking Speed ; ;0; ;;
¾ The speed at which the module tries to synchronize the ACout with the Main
¾ Possible Values:
Value
Variation of Frequency
(Hz/sec)
very fast -2 2,5
Fast -1 1,25
Normal 0 0,5
Slow 1 0,25
very slow 2 0,1
¾ When there are several TSI inverters in cascade: Upstream is the slowest and downstream is the fastest.
;101; ;Remote OFF disable ACin Power ; ;0; ;;
¾ 0 Normal mode
¾ 1 ACin power stage in converter is de-activated
¾ Allows for the deactivation of the ACin power in order to use this inlet as reference for the synchronization
¾ The load is then fed by the DC/AC converter. The ACin power is not used but ACout of inverter is still synchronized with
ACin wave (signal)
;102; ;Negative Power (0 : OFF, 1 : ON); ;1; ;;
¾ 0 ACin not allowed to re-inject to the Mains (only for factory test)
¾ 1 Allows the ACin to re-inject to the Mains when load re-injects (module’s default value)
