Certikin MB35C - Wall Terminal Dimensions; Heater Dimensions

Heater Dimensions
Pipe Connections
& Locations
Condensing Pool Heater 7 14/11/06
Fig. 3.0
559
217
126
C
351
505
101
A
291
B
157
400
990
950
Dimensions
Model ABC lh side C rh side
Genie 35 165mm 385mm
Genie 50 197mm 449mm
252mm 270mm
G
H
J
K
E
D
F
Connections
D Multi Heater Connection
E External Control (CCP01)
F Electric In
G Gas Supply - 22mm Copper
H Condensate Drain - 40.1mm Hunter Plastic
J From Pool - 1½” Plastic Demountable Fittings
K To Pool - 1½” Plastic Demountable Fittings
Fig. 3.1
Service Access
Left, Right or Above 300mm
In Front 800mm
Rear Flue Left/Right Flue
Horizontal Wall Terminal
Dimensions
Horizontal Wall Terminal
(MBHT)
SW
WT
WT
157
200
9
3
°
9
3
°
1065 1065
52mm
1000mm
3
°
