0-6
4.22 Fork dimensions s/e/l [mm] 35x100x1000 35x100x1000 35x100x1000
4.23 Fork carriage to DIN 15173, class/form A, B II A II A II A
4.24 Width of fork carriage b3 [mm] 900 900 900
4.31 Floor clearance, mast (with load) m1 [mm] 90 90 90
4.32 Floor clearance, centre of wheel-base (with load) m2 [mm] 90 90 90
4.33 Aisle width with pallets 1000x1200 across forks Ast [mm] 2893 3055 3109
4.34 Aisle width with pallets 800x1200 along forks Ast [mm] 3015 3177 3231
4.35 Turning radius Wa [mm] 1234 1396 1450
4.36 Minimum distance between the centres of rotation b13 [mm] --- --- ---
PERFORMANCE
5.1 Travel speed, with/without load km/h 12 / 12,5 12 / 12,5 12 / 12,5
5.2 Lifting speed, with/without load m/s 0,32 / 0,52 0,31 / 0,52 0,30 / 0,52
5.3 Lowering speed, with/without load m/s 0,59 / 0,52 0,59 / 0,52 0,59 / 0,52
5.5 Tractive force, with/without load N 1470 / 1670 1420 / 1670 1370 / 1670
5.6 Maximum tractive force, with/without load (S2 5 minute rating) N 7300 / 7500 f 7250 / 7500 f 7200 / 7500 f
5.7 Climbing ability, with/without load (S2 30 minute rating) % 8 / 12,5 7 / 11,5 6,5 / 11
5.8 Maximum climbing ability, with/without load (S2 5 minute rating) % 19 / 25 f 17 / 25 f 16 / 25 f
5.9 Acceleration time, with/without load s --- --- ---
5.10 Service brake: mechanical / hydraulic / electric / pneumatic hydraulic hydraulic hydraulic
MOTORE ELETTRICO
6.1 Drive motor, power (S2 60 minute rating) kW 5,1 5,1 5,1
6.2 Lift motor, power (S3 15% rating) kW 7,5 7,5 7,5
6.3 Battery according to DIN 43531/35/36 A, B, C, NO DIN 43535 A DIN 43535 A DIN 43535 A
6.4 Battery voltage / rated capacity (K5) V/Ah 24 / 400-500 24 / 700-875 24 / 800-1000
6.5 Battery weight kg 372 600 676
OTHERS
8.1 Type of drive control Inverter MOSFET Inverter MOSFET Inverter MOSFET
8.2 Working pressure for attachments bar 140 140 140
8.3 Oil flow for attachments l/min --- --- ---
8.4 Noise level at driver’s ear dB (A) --- --- ---
8.5 Towing coupling design / type DIN --- --- ---
a) With side shift = +34 mm b) 909 / 909 / 909 with 2M h3>4000 - 3M h3 > 4350 c) 881 / 909 / 909 with 2M h3>4000 - 3M h3 > 4350 d) + 150 mm raised version available
e) 1062 / 1062 / 1092 with 2M h3>4000 - 3M h3 > 4350 f) The shown values point out the electric motors capacity
