TECHNICAL AND WORKING SPECIFICATIONS FORKLIFT MODEL (Standard Version)
CHARACTERISTICS
1.1 Manufacturer CESAB CESAB CESAB
1.2 Model X243 1000 X243 1250 X243 1500
1.3 Power: electric (battery), diesel, petrol, LPG Electric Electric Electric
1.4 Operation: manual, pedestrian, stand-on, driver seated driver seated driver seated driver seated
1.5 Load capacity Q [Kg] 1000 1250 1500
1.6 Load centre c [mm] 500 500 500
1.8 Axle centre to fork face x [mm] 330 a 330 a 330 a
1.9 Wheel-base y [mm] 984 1146 1200
WEIGHTS
2.1 Weight kg 2550 2820 2930
2.2 Axle load with load, front/rear kg 2950 / 600 3390 / 680 3820 / 610
2.3 Axle load without load, front/rear kg 1100 / 1450 1230 / 1590 1280 / 1650
WHEELS - CHASSIS
3.1 Tyres: C=Cushion, PN=Pneumatic, SE=Superelastic, G=Twin C / SE / PN C / SE / PN C / SE / PN
3.2 Tyre size, front 457x152 / 18x7-8 / 18x7-8 457x152 / 18x7-8 / 18x7-8 457x152 / 18x7-8 / 18x7-8
3.3 Tyre size, rear 457x152 / 18x7-8 / 18x7-8 457x152 / 18x7-8 / 18x7-8 457x152 / 18x7-8 / 18x7-8
3.5 Wheels: number front/rear (x = driven) 2 / 1x 2 / 1x 2 / 1x
3.6 Track width, front b10 [mm] 837 / 837 / 847 b 837 / 837 / 847 b 881 / 837 / 847 c
3.7 Track width, rear b11 [mm] 0 0 0
DIMENSIONS
4.1 Mast tilt: forward / backward α /
β
[°] 3° / 6° 3° / 6° 3° / 6°
4.2 Height of mast, lowered h1 [mm] 2140 2140 2140
4.3 Free lift h2 [mm] 80 80 80
4.4 Lift height h3 [mm] 3270 3270 3270
4.5 Height of mast, extended h4 [mm] 3820 3820 3820
4.7 Height of overhead guard h6 [mm] 1980 d 1980 d 1980 d
4.8 Height of driver’s seat h7 [mm] 941 941 941
4.12 Towing coupling height h10 [mm] 615 615 615
4.19 Overall lenght I1 [mm] 2564 a 2726 a 2780 a
4.20 Lenght to fork face I2 [mm] 1564 a 1726 a 1780 a
4.21 Overall width b1\b2 [mm] 990 / 990 / 1030 e 990 / 990 / 1030 e 1062 / 990 / 1030 e
TECHNICAL DATA
