CESAB B 200 - Page 157

4-9
0
1
2
3
4
3
6
7
8
9
10
11
12
13
14
15
16
17
18
31 WATCHDOG LIFTING LOGIC UNIT: Self-diagnostic test 4-30
32 EEPROM KO LIFTING LOGIC UNIT: Fault in the memory area 4-30
33 LOGIC FAILURE #3 LIFTING LOGIC UNIT: Logic defect. 4-30
34 LOGIC FAILURE #2 LIFTING LOGIC UNIT: Fault in the hardware section 4-31
35 LOGIC FAILURE #1 LIFTING LOGIC UNIT: Protection from undervoltage/overvoltage 4-31
36 VMN LOW LIFTING LOGIC UNIT: Failure in the VMN test 4-32
37 VMN HIGH LIFTING LOGIC UNIT: Failure in the VMN test 4-33
38 CONTACTOR OPEN LIFTING LOGIC UNIT: Failure on the contactor 4-34
39 STBY I HIGH LIFTING LOGIC UNIT: Failure on the current sensor 4-34
40 CAPACITOR CHARGE LIFTING LOGIC UNIT: Capacitors not charged 4-35
41 HIGH TEMPERAURE LIFTING LOGIC UNIT: Logic unit temperature higher than 85°C 4-35
42
MOTOR
TEMPERATURE
LIFTING LOGIC UNIT: Traction motor temperature higher than
140°C
4-35
43 ENCODER ERROR LIFTING LOGIC UNIT: Encoder circuit fault 4-36
44
THERMIC SENSOR
KO
LIFTING LOGIC UNIT: Logic unit thermal detector out of range 4-37
45 SAFETY IN LIFTING LOGIC UNIT: Protection activated 4-37
46 CAN BUS KO LIFTING LOGIC UNIT: Reads the communication of another card 4-37
47 WAITING FOR NODE LIFTING LOGIC UNIT: It is detecting a delay in data transfer 4-38
48 AUX OUTPUT KO UNUSED 4-38
49 DRIVER SHORTED LIFTING LOGIC UNIT: Failure on the contactor driver 4-39
50 CONTACTOR DRIVER LIFTING LOGIC UNIT: Failure on the contactor driver 4-39
51 AUX COIL SHORTED LIFTING LOGIC UNIT: Failure on the contactor driver 4-39
52 VACC NOT OK LIFTING LOGIC UNIT: Steering potentiometer setting not correct 4-39
53
PUMP INCORRECT
START
LIFTING LOGIC UNIT: Seat open microswitch 4-39
54 SEAT MISMATCH LIFTING LOGIC UNIT: Seat open microswitch during traction 4-40
55
WRONG SET
BATTERY
LIFTING LOGIC UNIT: Battery voltage out of range 4-40
56 REMOTE INPUT UNUSED 4-40
57 BAD STEER 0-SET UNUSED 4-40
58 STEER SENSOR KO LIFTING LOGIC UNIT: Failure on the contactor driver 4-40
59 FORW + BACK UNUSED 4-40
81
PUMP INCORRECT
START
I/O CARD: Incorrect start 4-63
82 UNUSED UNUSED 4-63
83 PEDAL WIRE KO
I/O CARD: Failure in the signal of the accelerator potentiometer
at rest
4-63
84 BAD MICRO SWITCH I/O CARD: General alarm of broken microswitch 4-63
85 UNUSED UNUSED 4-63
When an Error Code is Displayed
Code Alarm specification Error mode Page
