CESAB B 200 - Page 158

4-10
86 BAD VACC
I/O CARD: Failure in the signal of the accelerator potentiometer
at rest
4-64
87 ERR SEAT I/O CARD: Does not see the seat microswitch closed. 4-64
88 UNUSED UNUSED 4-64
89 PARKING SELECTED I/O CARD: Failure on parking brake 4-64
90 UNUSED UNUSED 4-64
91 CONF ERROR I/O CARD: Configuration problem 4-65
92 BOOT ERROR I/O CARD: Comunication problem 4-66
93 NOT REP ERROR I/O CARD: Comunication problem 4-66
94 CHKSUM ERROR I/O CARD: Replace the I/O Control Board 4-66
0A SAFETY OUTPUT TRACTION LOGIC UNIT: Logic safety driver failure 4-25
0B SLIP PROFILE TRACTION LOGIC UNIT: Error in the memory data 4-25
0C ANALOG INPUT TRACTION LOGIC UNIT: Control internal error 4-25
0D HARDWARE FAULT TRACTION LOGIC UNIT: Control internal error 4-25
0E
POWER MOS
SHORTED
TRACTION LOGIC UNIT: Power circuit failure 4-26
0F FLASH CHECKSUM TRACTION LOGIC UNIT: Control internal error 4-26
1A SOFTWARE ERROR
TRACTION LOGIC UNIT: Memory error
4-26
1B THERMIC MOT KO
TRACTION LOGIC UNIT: Motor temperature sensor
disconnected
4-27
1C ENCODER LOCK TRACTION LOGIC UNIT: Motor encoder disconnected 4-27
1D UNUSED UNUSED 4-27
1E CONTACTOR CLOSED TRACTION LOGIC UNIT: Failure on the contactor driver 4-28
2A CHOPPER NOT CONF UNUSED 4-28
2B STEER WIRE KO TRACTION LOGIC UNIT: Steering potentiometer failure 4-28
2C DATA ACQUISITION TRACTION LOGIC UNIT: Logic in data acquisition phase. 4-28
2D WRONG 0 VOLT TRACTION LOGIC UNIT: Control internal error 4-29
2E HANDBRAKE TRACTION LOGIC UNIT: Brake microswitch failure 4-29
2F
WRONG RAM
MEMORY
TRACTION LOGIC UNIT: Protection against electrostatic
charges activated
4-29
3A SAFETY OUTPUT LIFTING LOGIC UNIT: Logic stop 4-41
3B SLIP PROFILE LIFTING LOGIC UNIT: Error in the memory data 4-41
3C ANALOG INPUT LIFTING LOGIC UNIT: Control internal error 4-41
3D HARDWARE FAULT LIFTING LOGIC UNIT: Control internal error 4-41
3E
POWER MOS
SHORTED
LIFTING LOGIC UNIT: Power circuit failure 4-42
3F FLASH CHECKSUM LIFTING LOGIC UNIT: Control internal error 4-42
4A SOFTWARE ERROR LIFTING LOGIC UNIT: Error in the memory data 4-42
4B THERMIC MOT KO LIFTING LOGIC UNIT: Motor sensor disconnected 4-43
4C ENCODER LOCK LIFTING LOGIC UNIT: Motor encoder disconnected 4-43
When an Error Code is Displayed
Code Alarm specification Error mode Page
