Installation 2M TV:
After installation, perform adjustment if necessary in
order to have following clearance of the upper fixing
bolts of the cylinders.
clearance = 4 (0 / -0.3) mm
Installation 3M TV:
After installation, perform adjustment if necessary in
order to have following clearance of the upper fixing
bolts of the cylinders.
clearance = 4 (0 / -0.3) mm
Installation 2M FFL:
After installation, perform adjustment if necessary in
order to have following clearance of the upper fixing
bolts of the cylinders.
clearance = 4 (0 / -0.3) mm
Installation 3M FFL:
Respect the orientation between holes G3/8 and M6
RH = right cylinder
LH = left cylinder
Installation 3M FFL:
After installation, perform adjustment if necessary in
order to have following clearance of the upper fixing
bolts of the cylinders.
clearance = 4 (0 / -0.3) mm
LH
RH
