12-44
REMOVAL • INSTALLATION
Note:
The explanation here is for the flow regulator valve for all the mast.
Tightening torque T=Nm
Removal procedure
1. Set the mast in vertical position and lift it up to reach the valve.
2. Disconnect the battery connector
3. Fix the mast with a chain-belt or with wood blocks in order to avoid the mast lowering.
4. Disconnect the flexible hose that connected to the control valve A
5. Remove the lowering valve
Installation procedure
The reassembly procedure is the reverse of the disassembly procedure.
2M TV 3M TV 2M FFL 3M FFL
