14-8
MAST PERFORMANCE TABLE
LIFTING
TILTING
WARNING:
The installation of a hydraulic control valve finalized to operate a clamp (for example a paper roll)
implicates an obligatory application of a double command device avoiding the risk of accidental
release of the load (ISO 3691-1, 5.4.4.1).
Q1 max. load Q2 max. load at max. height
Perform the test with the electrolyte density 1.18 ÷ 1.26 Kg/l, electrolyte temperature 20° ÷ 50°, oil temperature
30° ÷ 50° and environment temperature > di 18°C
1.0t
Load FFL TV
Kg m/sec amp bar m/sec amp bar
Q1 0,25 min max 330 max 135 0,25 min max 370 max 145
lowering
Q1 max 0,60
max 0,60
Lifting end stroke (max. pressure valve adjustment) max 410 max 175
1.25t
Load FFL TV
Kg m/sec amp bar m/sec amp bar
Q1 0,24 min max 380 max 160 0,24 min max 410 max 185
lowering
Q1 max 0,60
max 0,60
Lifting end stroke (max. pressure valve adjustment) max 450 max 215
1.5t
Load FFL TV
Kg m/sec amp bar m/sec amp bar
Q1 0,23 min max 410 max 180 0,23 min max 450 max 205
lowering
Q1 max 0,60
max 0,60
Lifting end stroke (max. pressure valve adjustment) max 480 max 235
Perform the test to height 1 m and with load = Q1
Tollerance value of tilting angle: ± 0.5°
Tilting Std. = 5° AV; => 6° IN
degree / sec amp bar
BW - FW 2,5 3,8 max 55 max 40
FW - BW 2,9 4,6 max140 max120
Tilting end stroke lever control valve max 150 max 160
Tilting end stroke electric control valve max 240 max 240
Std. sideshift stroke 100 mm: visible check
