Model 1,0 ton 1,3 ton 1,5 ton
Rear axle
Model ZF GK26LD
Reduction ratio 1:27
Quantity of oil 6,2 litri
Type of oil (standard version) MOBILUBE OIL 1 HD 80W-90
Type of oil (cold storage version) MOBILUBE OIL 1 SHC 75W-90
Tightening torque of fixing motor gear/chassis 283 Nm (± 5%)
Brakes
Type of service brake Drum
Strenght of service brake 5,50 kN
Type of parking brake Drum
Strenght of parking brake 4,50 kN
Diameter of brake wheel 170 mm
Thickness of brake wheel 40 mm
Area of brake shoe 6073 mm² (for shoe)
Thickness of brake shoe 5 mm
Wheels
Type
Super Elastic (SE)
Pneumatic (PN)
Cushion (CU)
Front wheel (SE/PN) 18X7-8
Rear wheel (SE/PN) 18X7-8
Cushion front wheel (CU) 457X152X308
Cushion rear wheel (CU) 457X152X308 457X178X308
Pneumatic wheel pressure 10 bar
Tightening torque of fixing wheel/hub 140 Nm (± 5%)
