17-4
Model 1,0 ton 1,3 ton 1,5 ton
Contactor
Key contactor - CT1 SW60B-230 24V
Traction contactor - CT2 SU280B-1004 24V CO
CT1 coil 104 ohm
CT2 coil 45 ohm
Tightening torque of fixing cables CT1 3,6 ÷ 3,9 Nm
Tightening torque of fixing cables CT2 15,3 ÷ 16,4 Nm
Hydraulic pump
Type of pump gear
Model of pump WSP 20-8
Pump transmission direct motor drive
Pump capacity 12,45 l/min (1500 rpm)
Displacement pump 8,74 cm³
Steering
Type of power steering Dynamic
Orbitrol model OSPC 50 LS
Orbitrol maximum pressure 100 bar
Orbitrol oil capacity 8 l/min
Orbitrol displacement 50 cm³
Model of priority valve OLSP 80
Tightening torque of fixing priority valve/pump 12 Nm (± 15%)
Tightening torque of fixing orbitrol/steering column 40 Nm (± 15%)
Tightening torque LS channel/orbitrol 35 Nm (± 10%)
Tightening torque orbitrol connection 55 Nm (± 10%)
Traction/pump logic unit
Model ACE-2
Maximum current 500 A
Fuse 80V 350A
Tightening torque of cables 13 ÷ 15 Nm
