CESAB B 200 - Page 443

17-5
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
17
15
18
Model 1,0 ton 1,3 ton 1,5 ton
Mechanical control valve
Lifting maximum pressure 175 bar 215 bar 240 bar
Tilting maximum pressure 130 bar
Sideshift maximum pressure 130 bar
IV way maximum pressure 130 bar
Lifting oil capacity 30 l/min
Tilting oil capacity 13 l/min
Sideshift oil capacity 13 l/min
IV way oil capacity 13 l/min
Lifting solenoid valve resistence 28 ohm
Tilting solenoid valve resistence 28 ohm
Electrical control valve
Lifting maximum pressure 175 bar 215 bar 240 bar
Tilting maximum pressure 130 bar
Sideshift maximum pressure 130 bar
IV way maximum pressure 130 bar
Lifting oil capacity 40 l/min
Tilting oil capacity 12 l/min
Sideshift oil capacity 12 l/min
IV way oil capacity 25 l/min
Solenoid valve resistence EV2 (lifting) 27 ohm
Solenoid valve resistence EVP1 (lowering) 18 ohm
Solenoid valve resistence EVP3 e EVP4 (tilting) 18 ohm
Solenoid valve resistence EV5 e EV6 (sideshift) 19 ohm
Solenoid valve resistence EV7 e EV8 (IV way) 19 ohm
Solenoid valve resistence EVP (drain) 18 ohm
