CESAB B 200 - AUXILIARY WIRING HARNESS

17-6
AUXILIARY WIRING HARNESS
J131
J20
J93
J102
J81
JT
J70
J14
J15
J50
J52
J2
J92
J91
JP
J48
J23
J11
J31
J13
J3
J107/A
J34J40
J32
J33
J29A
J21
J30
J35
J4
J90
J71
J132
J137
J82
J133/A
J133
Connector
J2
J3
J4
J11
J13
J14
J15
J20
J21
J23
J29
J29/A
J30
J31
J32
J33
J34
J35
J40
J48
J50
J52
J70
J71
J81
J82
J90
J91
J92
J93
J102
J107/A
J131
J132
J133/A
J133
J137
JP
JT
Description
Traction motor
Pump motor
Oil brake tank
Horn
Pump motor
Steering pot
Traction motor
Seat
Emergency button
Valves
Swaying pedal
Cap
Parking brake
Brake pedal
Accelerator pedal
Direction pedal
I/O board
Steering column
I/O board
Distributor/MHYRIO
Contactor / Fuses
Contactor / Fuses
Buzzer
Buzzer
Negative
+V out key
Optional fuses
Left light equip.
Left light equip.
Right light equip.
Right light equip.
Heater
Armrest
Can-Bus tap
Jumper connection
+24V Can-Bus tap
Dashboard
Pump controller
Traction controller
