Guide for Upgrading the Firmware on the ASX-520 and ASX-520HS Autosamplers with an EXR-8
3
Figure 1-2. View of Y- axis home block with Kynar thumbscrews.
Figure 1-3. Z-drive removed from arm assembly.
3. Remove the whole Z-drive assembly from the arm by pulling the whole Z-drive assembly
forward and off the autosampler arm (Figure 1-3).
