98
Engine Oil Change
• Place and park the vehicle on level ground.
• Start and idle the engine for 2-3 minutes, and then stop
the engine�
• Place a pan under the engine oil drain hole
1
to collect
the used engine oil.
• Remove the dipstick and clean it.
• Remove the magnetic drain bolt to drain out the oil.
• Make sure the engine oil in the crankcase is drained
completely�
• Install and tighten the drain bolt to the specied torque.
Drain Bolt Torque: 18�5 ft-lb� (
25 N·m
)
• Use a dry and clean cloth to wipe the area around
magnetic drain bolt.
• Add the recommended type of oil into oil dipstick hole
to the specified range by using the funnel assembly of
funnel, funnel extension tube and tube adapter.
• Remove the funnel assembly, make sure the oil level is
between the upper and lower marks with the dipstick, and
adjust the oil level accordingly.
1
