MAINTENANCE & LUBRICATION
111
Wheel and Tires
Removal and Installation
Removal
:
• Elevate the vehicle using a jack and support stands.
• Remove four bolts
1
�
• Remove the wheel for replacement.
Installation:
• Install the wheel
A
and the nuts
B
�
• Lower the ATV to make sure the wheels are on the
ground.
• Torque the wheel nuts to specication.
Wheel nut torque: 44 ~ 48 ft-lb� (60 N•m ~ 65 N•m)�
1
A
B
B
