FEATURES & CONTROLS
51
Foot Brake
The foot brake pedal
1
is located on the right side oor board of the vehicle. Stepping down on the pedal
applies the front and rear brakes at the same time.
When applied, the pedal should feel rm. A soft brake pedal would indicate a possible uid leak or low
master cylinder uid level, which must be corrected before riding. Contact your dealer for proper diagnosis
and repair�
WARNING
Operating the ATV with a spongy brake lever or pedal can result in loss of control, which could cause an
accident�
1
