MAINTENANCE & LUBRICATION
114
Chain Tension Inspection
Shift to Neutral gear;
Push up the chain and check its tension;
If the chain tension is out of specification, adjust it to the
standard�
Standard value: 0�19 in� ~ 0�59 in� (5 mm ~ 15 mm)�
NOTE:
The wear of chain is not always the same. Rotate the rear wheel
to repeat the measurement at dierent positions.
NOTE
For your safety, please use the original chain suggested by
CFMOTO. If the chain is elongated, never cut the chain and
reuse it. Have it replaced by an authorized CFMOTO dealer.
Inspect the rear sprocket and motor sprocket teeth for any kind
of wear.
If the motor sprocket or rear sprocket is worn or damaged, then
replace the whole transmission assembly.
Standard Teeth
Worn Teeth
Damaged Teeth
5 mm ~ 15 mm
