Chainway C3000 - 7.3 GPS

Pic 7-2-1
High Frequency (13.56MHz)
Operating Frequency: 13.56HMZ
Protocol: ISO14443A/B, ISO15693;
Types of cards: HF S50, S70 and ultralight
Ultra High Frequency (840~960MHz)
Pic 7-2-2
1) Protocol: EPC, GEN2/ISO 18000-6C
2) Operating Frequency: 840~960MHz
 China Standard 920-925MHz;
 China Standard 840-845MHz;
 ETSI 865-868MHz;
 Customization 915MHz;.
3) Power: 10~30dBm, and 24/25 dBm is recommended, the higher power, the higher
battery consumption;
4) Antenna Gain: 3dBi;
5) Reading/Writing Distance: the actual distance depends on multiple elements
including the tags, the using environment, the working frequency, and the power.
7.3 GPS
The GPS module allows to locate the dynamic position including longitude/latitude data of the
device. It is recommended to use outdoor. Pic 7-3-1
RFID Sensing Zone
