4.0 Schematics & Parts Lists
23
70000 Main Assembly – Arch Parts List
NO.
PART NO.
DESCRIPTION
QTY
1
10004-3
CLAMP
1
2
10007-2
ARCH
1
3
11288-38
WASHER/SPACER
2
4
43034
ACTUATOR- CLAMP UP
1
5
E-866-4
MICROSWITCH
1
6
EE-3416
POWER PANEL W/HOOD
1
6
EE-3442
POWER PANEL W/EYES
1
7
H-6918-610
SCREW - 3/8-16 X 1-1/4 SOCKET HEAD CAP
2
8
H-7327-12
WASHER - 3/8 MEDIUM LOCK
2
