Challenge TITAN 200BC - Page 33

4.0 Schematics & Parts Lists
33
70000 Main Assembly – Stand Parts List
NO.
PART NO.
DESCRIPTION
QTY
1
40016-8
MOUNT - VIBRATION
4
2
41014
SWIVEL CASTER WITH BRAKE
3
3
42057-1
FOOT BRACKET
OPT
4
44084
JACKSCREW - TABLE
2
5
51036
FOOT
OPT
6
70100
STAND WELDMENT - TITAN 200
1
7
71009
HYD. UNIT MOUNTING PLATE
1
8
E-2196-11
HOLE PLUG
1
9
E-2196-15
HOLE PLUG
2
10
E-2196-21
HOLE PLUG
2
11
E-3422-3
PUSHBUTTON SWITCH
1
12
EE-3022-1
POWER CORD ASSEMBLY
1
13
H-477-4
HYDRAULIC POWER UNIT ASSEMBLY- 120V, 60HZ
1
14
H-6414-6
NUT - 3/8-16 WHIZ LOCK
4
15
H-6423-5
NUT - 5/16-18 HEX KEP
12
16
H-6424-8
NUT - 1/2-13 HEX JAM
OPT
17
H-6913-508
SCREW - 5/16-18 X 1 HEX HD
16
18
H-6918-505
SCREW - 5/16-18 X 5/8 SOC HD
4
19
H-6938-848
SCREW - 1/2-13 X 3 CUP SOC SET
OPT
20
H-7321-5
WASHER - 5/16 SAE PLAIN
4
21
H-7327-10
WASHER - 5/16 MEDIUM LOCK
8
