4.0 Schematics & Parts Lists
35
70000 Main Assembly – Covers Parts List
NO.
PART NO.
DESCRIPTION
QTY
1
14050
SERIAL PLATE
1
2
43041-2
COVER- REAR STAND (TOP)
1
3
43044-1
COVER- REAR STAND
1
4
70022
LOWER FRONT COVER
1
5
70023-1
TOP COVER
1
6
70024
BACKGAUGE COVER- SHEET METAL
1
7
70100
STAND WELDMENT - TITAN 200
1
8
H-6910-102404
SCREW - #10-24 X 1/2 BUTTON HEAD CAP
16
9
H-6910-404
SCREW - 1/4-20 X 1/2 BUTTON HEAD CAP
6
10
S-1781-16
LABEL- CRUSH HAZARD
2
11
S-1781-203
LABEL- INTERCONNECTION (W/HOOD)
1
11
S-1781-207
LABEL – INTERCONNECTION (W/EYES)
12
S-1781-50
LABEL - ELECTRIC SHOCK
2
