Challenge TITAN 200BC - Page 46

4.0 Schematics & Parts Lists
46
Power Panel Assembly – Parts List
EE-3442 - REV. “A”
NO.
PART NO.
DESCRIPTION OF ACCESSORIES
QTY
1
70009
PANEL - ELECTRICAL
1
2
EE-2897-1
P.C.B. ASSEMBLY - CONTROLLER
1
3
E-2805-4
STARTER - CONTACTOR
1
4
E-2742-7
TRANSFORMER - 120/208/230V PRIM.,(T1)
1 1
5
E-1977-18
RAIL - TERMINAL BLOCK, 6-1/2" LONG
1 1
6
E-2070-1
END BRACKET - TERMINAL BLOCK
2
7
E-3264-14
CIRCUIT BREAKER - 12A (120V OPT. ONLY)
1
8
E-2626-5
TERMINAL STRIP - 5 POS.
1
9
E-1152-56
STAND-OFF - 1/2" LONG, #6-32 THR'D
4
10
E-2066-10
CONNECTOR - PLUG IN PCB TERMINAL BLOCK
1
11
E-2066-6
CONNECTOR - PLUG IN PCB TERMINAL BLOCK
1
12
E-866-4
SWITCH - MICRO., CLAMP UP LIMIT
1
13
EE-3419-1
WIRES - CUT LENGTH CHART
1
14
EE-3081-3
PCB ASM. - LINE LIGHT
1
15
EE-2769-20
CABLE ASM. - CUT SOLENOID
1
16
E-3437-3
SWITCH - CUT BUTTON (1) N.O. & (1) N.C.
2
17
H-6923-44012
SCREW - #4-40X 3/4" RD HD
4
18
H-6910-102404
SCREW - #10-24 X 1/2 BUT HD
4
19
H-6910-63203
SCREW - #6-32 X 3/8" BUT HD
6
20
H-6423-#6
NUT - #6-32 HEX (KEP)
4
21
H-7324-#6
WASHER - #6 INT. TOOTHLOCK
6
22
H-6910-102403
SCREW - #10-24 X 3/8" BUT HD
2
23
H-7324-#10
WASHER - #10 INT. TOOTHLOCK
2
24
H-6910-403
SCREW - 1/4-20 X 3/8" BUT HD
1
25
H-7324-8
WASHER - 1/4" INT. TOOTHLOCK
1
26
E-1584-( )
LABEL - PART NUMBER/ REVISION LEVEL
1
27
E-1584-51
LABEL - TRANSFORMER, "T1"
1
28
S-1694
CABLE TIE
5
29
S-1781-42
LABEL - GROUND (SECONDARY)
1
30
E-3370
RELAY - SAFETY OUTPUT (E-3336 REF)
1
31
E-2810
POWER SUPPLY - 24V OUTPUT
1
32
EE-3105-2
CABLE ASM. - ENCODER (SUPPLY W/PANEL)
1
33
E-3370
LIGHT CURTAIN SET - 16" STANDARD
1
34
43096-1
BRACKET - LIGHT CURTAIN, RH
1
35
43097-1
BRACKET - LIGHT CURTAIN, LH
1
36
H-6423-#10
NUT - #10-24 HEX (KEP)
4
37
16566-1
BOX - CUT BUTTON
2
38
EE-3440
CABLE ASSEMBLY - CUT SWITCH - RH
1
39
EE-3441
CABLE ASSEMBLY - CUT SWITCH - LH
1
40
S-1350-16
STRAIN RELIEF
2
