4.0 Schematics & Parts Lists
55
K-70027 Foot Pedal Kit Parts List
NO.
PART NO.
DESCRIPTION
QTY
1
40016-3
MOUNT- VIBRATION
2
2
41033
BRACKET- CLAMP UP
1
3
43022
PEDAL
1
4
43023
CLEVIS PIN
2
5
43024
HAIRPIN COTTER
2
6
43074
ROD - CLAMP CYLINDER
1
7
43076
ACTUATOR - HYDRAULIC UP PROX.
1
8
43077
CABLE- FOOT PEDAL
2
9
47086
PIN- BELL CRANK
2
10
47136-3
1-3/4" OD EXTENSION SPRING
2
11
47136-4
7/8" OD EXTENSION SPRING
2
12
E-866-4
MICROSWITCH
1
13
EE-3033
CABLE ASM- CLAMP UP SWITCH EXTENSION
1
14
H-6423-4
NUT - 1/4-20 HEX KEP
8
15
H-6423-#4
NUT - #4-40 HEX KEP
2
16
H-6910-403
SCREW - 1/4-20 X 3/8 BUTTON HEAD CAP
2
17
H-6913-406
SCREW - 1/4-20 X 3/4 HEX HEAD CAP
2
18
H-6922-44012
SCREW - #4-40 X 3/4 FLAT HEAD CAP
2
19
H-6938-532
SCREW - 5/16-18 X 2 CUP SOC SET
2
20
H-7321-4
WASHER - 1/4 SAE PLAIN
10
21
H-7324-8
WASHER - 1/4 INT TOOTH
2
22
S-1193-50
E-RING - 1/2"
4
23
S-1884
EYE BOLT W/ NUT
2
