FY –33VC Operation manual
- 30 -
Chapter 10
HEATING SYSTEM
10.1 Summary
This heating system can adjust temperature based on different PVC material and surrounding. It can
adjust the temperature automatically to keep temperature constant. Customer can have satisfactory
printing effect.
10.2 System Diagram
Figure 10-1 System Diagram
10.3 Function Description
1、To keep the front and rear heating boards in auto constant temperature.
2、 With advanced protective functions to avoid over-heating, leakage, etc. The line will be cut off
automatically if a certain line’s temperature is over 70° C. As soon as the temperature lowers, it will
resume heating. Over heating will not occur when the entire input signal is cut off.
3、 The system can work independently and can be easily transplanted. It is easy to convert input
voltage from AC110V to 220V.
4、 The heating system is controlled by advanced intelligent microprocessor; it has features of heating
up quickly, controlling temperature accurately and saving energy.
5、Inner heaters are used. It is easy to install, with no extra space needed and longer lifetime.
10.4 Working Process and Characteristics
1. The temperature of front and rear heater is already set in the factory. User cannot amend it.
2. Heating power supply is independent from control power supply. Please turn on the heating power
before turning on the power for the printer. Once the power is on, the system heats up
automatically to set temperature and keeps the temperature at the set value. Without turning on
▽
Front heatin
