Chapter 2
Technical Parameters
Figure2-1 Printer Outlook
Product Model FY-33VC
Print Technique Xaar 126 piezo head, 12 heads inside
Resolution
200dpi、400dpi
Color Quality Photo effect including 2 levels: Basic and High Quality
Max Media Width 3300mm
Max Printing Width 3250mm
Min Printing Size A4 or 21omm
Output (m²/h)
Mode
Level 10 Level 11
200dpi 2pass
40.85 47.36
200dpi 3pass
32.11 34.41
200dpi 4pass
24.92 25.42
Output (m²/h)
400dpi
24.92 25.42
Display LCD display with 8 key panel, self-diagnosis available
Ink Type
Solvent-base ink：C, M, Y, K
Ink Supply Mode
300ml/min auto ink supply by electric pump，volume of main tank
1000ml/color
Ink Inspection System Auto/manual ink supply, low ink detector
Printing Driver Support many RIP drivers
Operation Platforms Multi-operation platforms (Window2000, XP, etc.)
Media Type Flex, vinyl, window film, polyester, etc.
Media Transmission Roll media or sheet media (bigger than A4 or 210mm)
Media Processing Auto feeding and take-up system, weight less than 40kg/roll
Print head Height 2mm-4mm above media adjustable
Pre-heater & Dry System Auto heating after electrifying, the tiptop temperature is about 40°C
Clamp Manual adjustment media width
Print head Cleaning System Auto positive pressure cleaning
Safety System Inside safety lock with auto shutting down function
Print Interface
USB2.0 interface (
Window2000、NT、XP etc)
Noise
Printing status≤70dB/waiting status≤40dB (ISO7779)
Printer Size （ including ink
tank） / Net Weight
L 4610mm×W 875mm×H 1,250 mm / 550 kg
Package Size / Weight
L 4700mm×W 890mm×H 1,420 mm / 720 kg
