FY –33VC Operation manual
- 8 -
Chapter 3
Equipment Assembly and Adjustment
3.1 Assemble Printer
The whole packaging equipment is easy to assembly.
1. Please assemble supporter to a horizontal, clean and proper work area, tighten all screws on the
supporter to insure safety and stability;
2. Put main ink bottles to main ink bottle frame on the right side. Make sure to connect ink pipe to
correct ink holes;
Figure 3-1 Main ink bottles
3. Fixing Xaar print head 126 on supporter;
Figure 3-2 Print head frame
1—Up screw 2—Left screw 3—Right screw
Ink hole
1
2
3
