Chamberlain CSL24UL User Manual

10
Step 1 Determine Location for Operator
Check the national and local building codes before installation.
Standard Installation
1. The gate operator should be installed near the front roller of the gate. Lay out the concrete pad.
2. Install the electrical conduit.
3. Pour a concrete pad (reinforced concrete is recommended).
Rear Installation
1. The gate operator should be installed near the back of the gate in the OPEN position. Lay out the concrete pad.
2. Install the electrical conduit.
3. Pour a concrete pad (reinforced concrete is recommended).
INSTALLATION

Chamberlain CSL24UL Specifications

General

Brand	Chamberlain
Model	CSL24UL
Category	Gate Opener
Language	English
