Troubleshooting Chart
SYMPTOM POSSIBLE CAUSES SOLUTIONS
Operator does not
run and diagnostic
display not on.
a. No power to control board
b. Open fuse
c. If on battery power only, low or dead
batteries
d. Defective control board
a. Check AC and battery power
b. Check fuses
c. Charge batteries by AC or solar power or replace batteries
d. Replace defective control board
Control board
powers up, but
motor does not
run.
a. Reset switch is stuck
b. Stop button active or jumper not in place
for stop circuit
c. If on battery power only, low or dead
batteries
d. Open or Close input active
e. Entrapment Protection Device active
f. Vehicle loop detector or probe active
g. Defective control board
a. Check reset switch
b. Check Stop button is not “stuck on”, or verify that the stop button is a
normally closed circuit, or put a jumper on the stop circuit.
c. Charges batteries by AC or solar power or replace batteries
d. Check all Open and Close inputs for a “stuck on” input
e. Check all Entrapment Protection Device inputs for a “stuck on” sensor
f. Check all vehicle detector inputs for a “stuck on” detector
g. Replace defective control board
Gate moves, but
cannot set correct
limits.
a. Gate does not move to a limit position
b. Gate is too difficult to move
c. Limits are set too close (slide gate
applications only)
a. Use manual disconnect, manually move gate, and ensure gate moves
easily limit to limit. Repair gate as needed.
b. Gate must move easily and freely through its entire range, limit to limit.
Repair gate as needed.
c. Ensure the gate moves at least four feet between the OPEN limit and the
CLOSE limit.
Gate does not fully
open or fully close
when setting
limits.
a. Gate does not move to a limit position
b. Gate is too difficult to move
a. Use manual disconnect, manually move gate, and ensure gate moves
easily limit to limit. Repair gate as needed.
b. Gate must move easily and freely through its entire range, limit to limit.
Repair gate as needed.
Operator does not
respond to a wired
control/command
(example: Open,
Close, SBC, etc.)
a. Check Open and Close command input
LEDs
b. Stop button is active
c. Reset button is stuck
d. If on battery power only, low or dead
batteries
e. Entrapment Protection Device active
f. Vehicle loop detector or vehicle probe
active
a. Check all Open and Close inputs for a “stuck on” input
b. Check Stop button is not “stuck on”
c. Check Reset button
d. Charges batteries by AC or solar power or replace batteries
e. Check all Entrapment Protection Device inputs for a “stuck on” sensor
f. Check all vehicle detector inputs for a “stuck on” detector
Operator does not
respond to a
wireless control or
transmitter
a. Check XMITTER LED when wireless
control is active
b. Stop button is active
c. Reset button is stuck
d. Poor radio reception
a. Activate wireless control and check XMITTER LED is on. Re-learn
wireless control/transmitter to control board. Replace wireless control as
needed.
b. Check Stop button is not “stuck on”
c. Check Reset button
d. Check if similar wired control operates correctly. Check if wireless
controls works properly when within a few feet of operator. Check
operator’s antenna and antenna wire. Check other wireless controls or
devices.
Gate stops during
travel and reverses
immediately.
a. Control (Open, Close) becoming active
b. Vehicle loop detector active
c. Low battery voltage
a. Check all Open and Close inputs for an active input
b. Check all vehicle detector inputs for an active detector
c. Battery voltage must be 23.0 Vdc or higher. Charge batteries by AC or
solar power or replace batteries
TROUBLESHOOTING
