OwnersCopy:SAVETHESEINSTRUCTIONSforfuturereference
MT50EVO
Sectional Garage Door Opener
I
nstallation and Operating Instructions
Thismanual contains IMPORTANT SAFETY information
DONOT PROCEED WITH THE INSTALLATION BEFORE READING THOROUGHLY
gomerlin.com.au
g
omerlin.co.nz
3
Manual
13
114A3361
ForService Call
InstallationDate
132A2900
RISKOF ENTRAPMENT
R
epeatSafety Reverse Test monthly Door
mustreverse on contact with a 40mm obstacle
placedon the floor Make necessary adjustments
AUTOMATICDRIVE:
Keepaway from the area of the door since it may
o
perateunexpectedly
EMERGENCYRELEASE:
T
orelease pull down firmly on the red handle
14
15
CARTON INVENTORY
Y
our garage door opener, rail and hardware are packed in a single carton.
2
RAIL SIZE
3
NOTE: The Ceiling Fixing Point is measured back from the lintel (see section 6 item 7 of “completed installation”). Also
allow 300 mm back from the fixing point for installation of the powerhead.
3
DOOR HEIGHT:
Sectional Doors
RAIL LENGTH: CEILING FIXING
POINT: (standard)
OVERALL LENGTH:
Up to 2.2 m
3000 mm
Segmented
2850 mm
3150 mm
(
1) Opener / powerhead
(2) Hand held remote
(3) Car visor remote
(4) Curved door arm
(5) Hanging bracket (2)
(6) Rail brackets (2)
(7) Lintel bracket
(8) Door bracket
(
9) Hardware bag
(10) Rail assembly (chain)
(11) Manual
(12) Warning Labels
(13) Rail centre bracket
(14) Rail mounting bracket
(15) Warranty card
