(1) Lintel bracket
(2) Chain (hidden)
(3) Rail
(4) Trolley
(5) Rail connecting piece
(6) Rail bracket
(7) Hanging bracket
(8) Power cord
(9) Opener
(10) Manual release rope & handle
(11) Straight door arm
(12) Curved door arm
(13) Door bracket
(14) Rail mounting bracket
(15) Centre rail bracket
As you proceed with the assembly, installation and adjustment procedures in this manual, you may find it helpful to
refer back to this illustration of a completed installation.
COMPLETED INSTALLATION
TOOLS REQUIRED
4
6
10 (8x)
9 (8x)
8 (8x)
7 (1x)
6 (1x)
1 (1x)
2 (1x)
3 (6x)
4 (6x)
5 (6x)
(1) Clevis pin 80 mm
(2) R clip
(3) Hexagonal head screw M8
(4) Nut M8
(5) Flat washer M8
(6) Clevis Pin
(7) R clip
(8) Screw ST6 x 50 mm
(9) Screw ST6 x 18 mm
(10) Wallplug 8mm
HARDWARE PROVIDED
5
To Next Page
