7
Operator Specifications
Usage Classification
Class I, II, III, & IV
Main AC Supply Model SL3000501UL 1/2 HP: 120 Vac, 6 Amps (12 Amps including accessory outlets)
Model SL3000101UL 1 HP: 120 Vac, 12 Amps (18 Amps including accessory outlets)
When Optional Transformer Kit Model 3PHCONV is installed in the field, operator is rated
208/240/480/575 VAC, 4.8/4.2/2.1/1.7 A, 60 Hz, 1 PH
Accessory Power
24 Vdc, 500 mA max. for ON + SW (switched)
Maximum Gate Weight Model SL3000501UL 1/2 HP: 1000 lbs. (453.6 kg)
Model SL3000101UL 1 HP: 2000 lbs. (907.2 kg)
Minimum Gate Travel Distance
4 feet (1.2 m)
Maximum Gate Travel Distance
52 feet (15.85 m)
Maximum Gate Travel Speed
1 foot/second
Maximum Daily Cycle Rate
Continuous
Maximum Duty Cycle
Continuous
Operating Temperature
Without Heater: -20°C to 60°C (-4°F to 140°F)
With Optional Heater: -40°C to 60°C (-40°F to 140°F)
Expansion Board
Provided
External Entrapment Protection Device Inputs (non-contact
and/or contact)
Main board - up to 2 close entrapment protection devices and 1 open entrapment
protection device.
Expansion board - up to 3 entrapment protection devices configurable to either close or
open and up to 4 edge sensors using wireless edge sensor kit model LMWEKITU .
INTRODUCTION
