Set Up
SET UP
CAUTION:
There may be more than one power source.
SET
UP
Drain Valve Operation:
Machine Checks:
• Check chemical supplies and make sure containers are full.
• Make sure all panels are properly installed.
• Remove protective plastic film from the machine exterior.
• Open doors and ensure they operate smoothly.
• Check the interior of the machine and remove foreign material.
• Make sure the pump strainers, scrap screens, and scrap baskets are installed.
• Make sure vent stack adjustment handles face the front of the machine.
• Open water supply and steam valves (if equipped). Check for leaks.
• Make sure the building drains are unobstructed.
• Make sure dishwasher area is clean, especially underneath the machine.
• Electric drain valves open and close automatically.
• Valve is closed when dishwasher power switch is ON.
• Valve opens for 10 minutes, then closes when dishwasher power switch is turned OFF.
• Turning the power switch ON and OFF again will open the valve for an additional 10 minutes.
• Valve closes at the end of 10 minutes.
• Refer to Appendix A: Electric Drain Valve Manual Operation, page 38.
Use a commercial grade NON-CHLORINATED detergent
in this dishwasher. Consult the chemical supplier for the rinse-aid
requirements.
Fig. 1 - Drain valves are electrically operated.
OPEN
