Cleaning
CLEANING
PUMP SUCTION STRAINER —
The wash pump suction strainer is located
on the side of the tank the prewash strainer at the bottom.
CAUTION: A clogged strainer reduces spray arm pressure
and significantly reduces wash performance.
The Wash tank strainer has a handle at the top and a strainer on the bottom.
Pull the handle straight up to remove. Flush strainer clean in a remote sink and re-install,
Fig. 69.
The prewash strainer is located at the bottom of the tank. Grasp the strainer by its sides
and lift up to remove. Note the retaining clips on the bottom of the strainer.
Flush the strainer clean in a remote tank inspect the drain and re-install.
1
2
Fig. 69 - Wash tank pump suction strainer
Handle
Screen
Retaining
Clips
Fig. 70 - Prewash pump suction strainer
