Parts List
Item no. Quantity Description Part no.
1 1 Handle G102-0001-9031
2 1 Lid G102-0002-0031
3 2 Hinge Bracket G102-0003-0031
4 1 Cooking Grate G102-0004-9081
5 1 Heat Distribution Plate G102-0005-0000
6 1 Burner G102-0100-0000
7 1 Heat Resistant Shield G102-0010-0000
8 1 Bottom G102-0006-0031
9 2 Ear Handle G102-0007-9031
Item no. Quantity Description Part no.
10 1 Regulator/Valve Set G102-0200-9000
11 2 Leg G102-0008-9081
12 6 Spacer G102-0009-9000
13 3 1/4” x 3/8” Screw 20120-13010-031
14 8 3/16” Hexagon Nut 30224-13000-031
15 4 3/16” x 3/4” Screw 20124-10018-031
16 4 3/16” x 3/8” Screw 20124-10010-031
17 2 15/64” Plain Washer 40100-13000-031
