Page #1 background image

Loading...

Page #1 background image

09/18/14 • G467-001-020801

466344015

If you have questions or need assistance

during assembly, please call 1-800-241-7548.

Si vous avez des questions ou besoin d´aide

pendant l’assemblage, S’il vous plaît appelez

1-800-241-7548

Serial number | Numéro de série

Date purchased | Date d’chat

See rating Label on grill for serial number.

Ce numéro se trouve sur l´étiquette signalétique sur

i´appareil.

4-Burner Gas Grill

Questions and Answers:

A
Amber GoodwinAug 14, 2025
Why does my Char-Broil 466344015 have a sudden drop in gas flow or low flame?
- B
  Brent VincentAug 15, 2025
  A sudden drop in gas flow or low flame in your Char-Broil Grill can happen for a few reasons. First, check if you are out of gas in the LP cylinder. If that's not the issue, the excess flow valve might have tripped; try turning off the knobs, waiting 30 seconds, and then lighting the grill. If the flames are still low, turn off the knobs and LP cylinder valve, disconnect the regulator, reconnect it, perform a leak test, turn on the LP cylinder valve, wait 30 seconds, and then light the grill. Lastly, a vapor lock at the coupling nut/LP cylinder connection could be the cause; turn off the knobs and LP cylinder valve, disconnect the coupling nut from the cylinder, reconnect it, and try again.
S
Sarah KnightAug 18, 2025
What to do if one burner does not light from other burners on my Char-Broil 466344015?
- C
  Christina MoralesAug 18, 2025
  If one burner on your Char-Broil Grill does not light from the other burners, it is likely due to grease buildup or food particles in the end(s) of the carryover tube(s). Clean the carry-over tube(s) with a wire brush.
K
Kathryn RogersAug 21, 2025
What to do if no sparks appear at any electrodes when Electronic Ignition Button is pressed and no noise can be heard from spark module in Char-Broil Grill?
- M
  Matthew RamirezAug 21, 2025
  If no sparks appear at any electrodes when the Electronic Ignition Button is pressed, and no noise can be heard from the spark module on your Char-Broil Grill, it could be due to several reasons: 1. The battery may not be installed properly; ensure that the '+' and '-' connectors are oriented correctly, with '+' on the cap end. 2. The battery may be dead; replace it with a new alkaline battery. 3. The button assembly may not be installed properly; unscrew the button cap assembly and reinstall, making sure the threads are aligned and engaged fully. 4. The spark module may be faulty; replace the spark module assembly.
J
Jeffrey MarshallAug 25, 2025
What to do if no sparks appear at any electrodes when Electronic Ignition Button is pressed but noise can be heard from spark module in Char-Broil 466344015?
- T
  tylerhopkinsAug 25, 2025
  If no sparks appear at any electrodes when the Electronic Ignition Button is pressed, but noise can be heard from the spark module in your Char-Broil Grill, the output lead connections may not be connected. Remove and reconnect all output connections at the module and electrodes.
M
mallory14Aug 28, 2025
What to do if sparks are present but not at all electrodes and/or not at full strength on my Char-Broil 466344015 Grill?
- J
  James PetersAug 28, 2025
  If sparks are present but not at all electrodes and/or not at full strength on your Char-Broil Grill, it could be due to several reasons: * Output lead connections not connected: Remove and reconnect all output connections at module and electrodes. * Arcing to grill away from burner(s): If possible, observe grill in a dark location. Operate ignition system and look for arcing between output wires and grill frame. * Weak battery: Replace battery with a new alkaline battery. * Electrodes are wet: Use a paper towel to remove moisture. * Electrodes cracked or broken 'sparks at crack': Replace cracked or broken electrodes.
F
fkingAug 31, 2025
What to do if my Char-Broil 466344015 Grill has a flare-up?
- R
  rodriguezpennyAug 31, 2025
  A flare-up in your Char-Broil Grill can occur due to several reasons. It could be caused by grease buildup, so cleaning the burners and the inside of the grill/firebox is recommended. Another cause may be excessive fat in the meat; trimming the fat before grilling can help. Lastly, excessive cooking temperature can also lead to flare-ups, so adjust the temperature accordingly to a lower setting.
W
William PerrySep 3, 2025
What to do if the flames blow out on my Char-Broil 466344015 Grill?
- C
  Carrie RichardsonSep 3, 2025
  If the flames on your Char-Broil Grill are blowing out, it could be due to high or gusting winds; turn the front of the grill to face the wind or increase the flame height by turning the gas valve to a higher position. Another reason could be low LP gas, in which case you should refill the LP cylinder. An excess flow valve tripped can also cause this problem; refer to the 'Sudden drop in gas flow' section for troubleshooting.
O
oscarcameronSep 7, 2025
What to do if my Char-Broil 466344015 has a persistent grease fire?
- F
  farleyamySep 7, 2025
  If you have a persistent grease fire in your Char-Broil Grill, it's likely due to grease trapped by food buildup around the burner system. Turn the knobs to OFF and turn the gas off at the LP cylinder. Leave the lid in position and let the fire burn out. After the grill cools, remove and clean all parts.
A
andersonstevenSep 12, 2025
How to fix a flashback (fire in burner tube(s)) in my Char-Broil 466344015?
- T
  Thomas HartmanSep 12, 2025
  If you experience a flashback (fire in burner tubes) in your Char-Broil Grill, it indicates that the burner and/or burner tubes are blocked. Turn the knobs to OFF and clean the burner and/or burner tubes.

Char-Broil 466344015 Specifications

General

Brand	Char-Broil
Model	466344015
Type	Gas Grill
Fuel Type	Liquid Propane
Burners	4
BTU	40, 000
Burner Material	Stainless Steel
Dimensions	51.2 x 24.5 x 44.5 in
Weight	85 lbs
Grates Material	Porcelain-coated Cast Iron
BTU Output	40, 000
Ignition	Electronic

Summary

Safety and Installation

Safety Symbols and Warnings

Explains safety symbols like Danger, Warning, and Caution.

LP Cylinder Safety Precautions

Details safety precautions for LP cylinders and potential hazards.

Installation Safety Precautions

Covers safe installation practices and connecting gas components.

Leak Testing and Safety Tips

Provides instructions for leak testing and general grill safety tips.

Grill Operation and Grilling Guide

Safe Grill Operation and Lighting

Explains safe grill usage, ignition, and match-lighting procedures.

Cooking Techniques and Food Safety

Covers cooking methods, food safety, and temperature guidelines.

Grilling Tips and Tricks

Advice on sauces, marinades, wood chips, and utensil usage for enhanced grilling.

Maintenance, Troubleshooting, and Emergencies

Grill Cleaning Procedures

Guides on cleaning various grill parts and the burner assembly.

Troubleshooting Common Issues

Addresses problems with ignition, gas flow, and flame issues.

Emergency Procedures

Steps to follow in case of gas leaks or fires for immediate safety.

Parts, Hardware, and Warranty

Limited Warranty Information

Details the product warranty coverage, terms, and limitations.

Parts Identification

Visual and listed identification of all grill components and hardware.

Product Registration

How to Register Your Product

Provides methods and instructions for registering the grill for warranty.
